1. Reduce mold cost and development cost. It can be arbitrarily changed according to the designer's design requirements to achieve half-etching of the metal surface, increase the company's LOGO, achieve brand transformation, and use it against theft.
2. The sample development cost is low, the precision is extremely high, the precision can reach +/-0.02mm, the thinner the material, the higher the precision control.
3. The development cycle is short and the sample delivery time is fast.
4. Products with complex shapes can also be etched without additional cost. It can also cope with miniaturization and diversification. ZYH has the opportunity to realize customized services for different customers at home and abroad, instead of only doing large-scale products.
5. No burr, no pressure point, solve many problems in stamping, laser cutting and other processes. At the same time, the precision can meet the product requirements, even better than the above-mentioned processes, and there is no substitute.
6. The manufacture of various metal parts that cannot be completed by mechanical processing. Stamping and laser processing cannot complete the processing of fine and ultra-thin materials, while the ZYH metal etching process is easier to handle.
Process comparison table
| Photo etching | Laser cutting | Stamping | Wire EDM | Water jet | Electroforming | |
|---|---|---|---|---|---|---|
| Sampling | Low cost | Low cost | High cost | Low cost | Low cost | Medium cost |
| Metals | Nearly all metals | Nearly all metals | Nearly all metals | Conductive metals | Nearly all metals | Nickel and copper |
| Hardness | No restriction | No restriction | Problems with soft, hard or brittle metals | Hardness is a consideration | Hardness is a consideration | Typically 200-670 HV |
| Stress | No stress | Thermal stress on cutting edge | Stress at cutting edge | Deformation, tempering and structural changes may occur | Limited stress on cutting edge | Low-stress |
| Burrs | No burring | Micro burring | Partial burring | Micro burring | Micro burring | No burring |
| Tooling and design changes | Quick, easy and cost effective | Quick, easy and cost effective | Expensive and time consuming | Quick, easy and cost-effective | Quick, easy and cost- effective | Quick, easy and cost-effective |
| Typical lead times | Seven days | Seven days | Six weeks - six months | Seven days | Seven days | Seven days |
| Tolerance as a percentage of metal thickness | ±10% | ±5% | ±10% | ±10% | ±15% | ±5% |
| Can parts be supplied in sheets for easy counting/handling? | Yes | Yes | Not easily | Yes | Yes | Yes |
